Required |
|||
| Product Description | OGA6900ES | ||
| Warranty | 3 years | ||
| Load required
|
5 pcs 60W bulb, 4 pcs 100W fan, 2 pcs 200W TV, 1 piece 75W Home Theatre, 1 piece 100W DVD, 1 piece 50W DSTV Decoder, 2 pcs 1.0hp AC, 1 piece 1.5hp AC, 1 piece 270W large size fridge/freezer | ||
Performance |
|||
| Power Output (Rated) | 5000 | ||
| Power Output (Max) | 5500 | ||
| Voltage | 230 | ||
| Current | 21.7 | ||
| Frequency | 50 | ||
| Voltage DC | 12 | ||
| Current DC | 8.3 | ||
| Design life *** | 1000 | ||
| Power factor | 1 | ||
| Fuel consumption (rated output) | 2.75 | ||
| Oil consumption | 0.77 | ||
| Noise level (7m from front side) | 75.90 | ||
| Life time | 1000 | ||
Electrical |
|||
| Start method | Electric + Recoil | ||
| Socket | Locking, 2 | ||
| Battery type | BS, 14 Ah | ||
| Plug | Locking Plug | ||
| Digit AVR | No | ||
| Remote controller | No | ||
| ATS | No | ||
Engine |
|||
| Model | 183FE/P-F | ||
| Supplier | ZONGSHEN | ||
| Material | Aluminium | ||
| Cooling style | Forced air cooling | ||
| Cylinder Qty | single | ||
| Bore | 83 | ||
| Stroke | 66 | ||
| Displacement | 357 | ||
| Max Power | 8.0 | ||
| Smart throttle | No | ||
| Compression ratio | 8.2:1 | ||
| Oil capacity | 1.1 | ||
| Carburettor automatic fuel shut-off | Yes | ||
| Low oil shut down | Yes | ||
| Recoil starter handle direction | 2 O ‘ clock | ||
| Fuel Recommended | 90#/93# | ||
| Gasket–Asbestos free | Yes | ||
Certification |
|||
| Safety Standard | SONCAP | ||
| Standard conformed | ISO9001 | ||
| Evaporative | N/A | ||
| Emission level | Euroll | ||
Alternator |
|||
| Rotor Windings | Copper | ||
| Stator Windings | Copper | ||
| Stack Length | ?190?125 | ||
| Excitation | Carbon brush | ||
| Temperature Rise (Rated Load) | ?110K | ||
| THD | ?25% | ||
Panel |
|||
| Main Circuit Breaker | 22 | ||
| Voltmeter, VFT 3 in 1 | Yes | ||
| Sockets | Locking | ||
| Engine Switch | Push | ||
| DC output | Yes | ||
| Material | Steel | ||
| Label | OGA6900ES | ||
| Certified parts | NO | ||
Frame |
|||
| Frame tube diameter | 25 | ||
| Paint–lead content | <90PPM | ||
| Paint colour | Black | ||
| Vibration absorber | 4 | ||
Wheel and Handle |
|||
| Wheel number | 2 | ||
| Wheel type | 9.5″ | ||
| Wheel colour | Yellow | ||
| Supporting foot | Single | ||
| Supporting foot colour | Black | ||
| Handle bar | 2 | ||
| Handle bar colour | Black | ||
| Handle bar sheath | PVC | ||
Fuel tank |
|||
| Tank Cap | Buckle | ||
| Ventilation Mode | Tank cap | ||
| Fuel spill direction | Toward recoil | ||
Colour scheme |
|||
| Frame colour | Black | ||
| Fuel tank colour | Yellow | ||
| Recoil starter colour | Yellow | ||
| Alternator end cover colour | Yellow | ||
| Control panel colour | Black | ||
Package |
|||
| Dimension(W*H*D) | 680 x 510 x 564 | ||
| Packing (W*H*D) | 700 x 530 x 585 | ||
| Net/Gross weight | 88.5/91 | ||
| Carton | 5 flutting paper | ||
| Recommended Stack Height | 5 layers | ||
Container Loading |
|||
| Qty?per /40”HQ | 288 | ||
Accessories Option |
|||
| Oil | No | ||
| Oil Funnel | Yes | ||
| DC wire | Yes | ||
| Plug | Yes | ||
| Warranty Card | Yes | ||
| Manual | Yes | ||
| Hardware Tooling | Yes | ||
FEATURES
